MediaTek Dimensity 1300 Complete review with benchmarks

(Last Updated On: May 27, 2022)

Description:

MediaTek Dimensity 1300- So, MediaTek just released a new chipset for smartphones with newly updated architecture, a slightly overclocked CPU, and GPU. So, I’m going to review its AnTuTu 9 scores, CPU performance, Graphics performance, Memory tests, Multimedia Performance, Connectivity, and gaming performance. In the end, I will tell you about its overall experience. So stay tuned.

MediaTek Dimensity 1300


Amazon Links:

Top smartphones

Cell Phone Chargers

Air buds

Smartphones Accessories

Apple Iphones

Samsung Phones

Tablets

Ipods

*Please Note: These are affiliate links. I may make a commission if you buy the components through these links. I would appreciate your support in this way!



MediaTek Dimensity 1300:

Over the last few years, MediaTek is leading in the mobile chip market, but in 2022 the company has gone so far with the record-breaking new chipsets. We’ve seen some amazing chipsets like MediaTek Dimensity 1200, MediaTek Dimensity 9000 which tops the AnTuTu 9 benchmarks, and MediaTek Dimensity 700 which was launched in Redmi note 10 5G, and many more smartphones. Now we have the full specs and full complete details of the MediaTek Dimensity 1300. Let’s start with AnTuTu 9.

AnTuTu 9:

CPU 186846
GPU 244789
Memory 119889
UX 133987
Total score 667021

MediaTek Dimensity 1300 shows the best AnTuTu 9 scores. We can see the big jump in the GPU performance. The total performance of the GPU is 244789, which is faster than the Qualcomm Snapdragon 860. The CPU also shows one of the best scores. It is 186846 which is a bit slower than the MediaTek Dimensity 1200. The memory scores also shows a significant boost and a score of 119889. Dimensity 1300 memory is faster than Qualcomm Snapdragon 860, MediaTek Dimensity 1200. The Ux is also showing one of the best performances. It is 133987, which is faster than Qualcomm Snapdragon 860, MediaTek Dimensity 1200. Total scores are above 667021. It will depend on which smartphone manufacturers using this chipset with which type of ram. MediaTek Dimensity 1300 is considerably gaining a performance boost and beating some of the latest processors in the Mid-rand category.


Geekbench 5:

Single-Core Score 938
Multi-Core Score 3181

The single-core scores show the best performance in this smartphone mid-range category lineup. The single-core scores are 938. And the multi-core scores are 3181 which is also good at this point.

CPU:

Architecture 1x 3 GHz – Cortex-A78
3x 2.6 GHz – Cortex-A78
4x 2 GHz – Cortex-A55
Cores 8
Frequency 3000 MHz
Instruction set ARMv8.2-A
Process 6 nanometers

MediaTek Dimensity 1300 launched with the Big 1 cores of Cortex-A78 which is an ultra-high performance core that is clocked on 3.00 GHz, and 3 cores of high performance which are clocked on 2.6GHz. The other 4 cores are based on Cortex-A55 and are clocked on 2GHz which is power efficiency cores. There is a little disappointment that why they haven’t used the Cortex X1 or X2. But the Cortex-A78 also has the best speeds and good set instruction architecture. There are a total of 8 cores with a boost clock of 3.00 GHz. MediaTek Dimensity 1300 has the latest set instruction architecture. It is not considered fast but it is strong enough to beat some of the latest and most powerful Chipsets. MediaTek Dimensity 1300 is fabricated on 6Nm. This means MediaTek Dimensity 1300 will be power efficient and will consume less battery and will produce less heat.


Graphics:

GPU name Mali-G77 MC9
Architecture Valhall
Vulkan version 1.1
OpenCL version 2.0
DirectX version 12

MediaTek Dimensity 1300 has a new architecture-based GPU. Valhall is the new architecture that they are using in the MediaTek Dimensity 1300. The GPU is also manufactured using the 6Nm technology. Which means it will also be power efficient. The name of the GPU is Mali-G77 MC9. This is the fastest GPU in this lineup. The Dimensity 1300 is fast enough to handle games like FREE FIRE, and PUBG MOBILE. The GPU score is faster than the MediaTek Dimensity 1300 which means there will be a smooth gaming experience on this chipset. The GPU is clocked on 950MHz. The shading units are also 256 which will help in rendering the graphics in gaming. There is also DirectX support of 12 which means this processor will support the latest games without any bugs and delays.

Memory:

Memory type LPDDR4X
Memory frequency 2133 MHz
Bus 4x 16 Bit
Max bandwidth 31.4 Gbit/s
Max size 16 GB

MediaTek Dimensity 1300 uses the new LPDDR4x ram with the memory frequency of 2133MHz and uses the bus of 4×16. The ram may be changed according to the smartphones. The memory frequency is also going to be changed according to smartphones. The max memory bandwidth is 31.4Gbit/s which is slower than the Qualcomm Snapdragon 860 which was used in Poco X3 Pro. The max ram support on this chipset is 16GB. This ram can be packed with the new UFS 3.1 storage thus will give you more read and write speeds.


Support:

Neural processor (NPU) Yes
Storage type UFS 3.1
Max display resolution 2520 x 1080
Max camera resolution 1x 200MP
Video capture 4K at 60FPS
Video playback 4K at 60FPS

MediaTek Dimensity 1300 uses their own neural engine which is fast with the AI calculations. MediaTek Dimensity 1300 uses the UFS 3.1 which is fast. This gives you fast read and writing speeds.

MediaTek Dimensity 1300 has the maximum display support of FullHD+ and can support the 120Hz refresh rate with the super Amoled. Dimensity 1300 is going to be very aggressive when it comes to a camera support. It supports a camera of up to 200MP. Samsung is working on a new 200MP camera sensor. This means next year we are going to see this chipset with a 200MP camera sensor. The video capture is kept on 4k at 60FPS and the video playback is also 4k at 60FPS. There is no 8k support on this MediaTek Dimensity 1300. It is a bit of a shame to see there is no 8k support on a 2022 flagship processor.



Connectivity:

5G support Yes
Wi-Fi 6
Bluetooth 5.2

MediaTek Dimensity 1300 has 5G support. The MediaTek Dimensity 1300 also comes with the Wi-Fi 6 and the Bluetooth version of 5.2. This will give you better signals and better speeds. MediaTek Dimensity 1300 uses the X62 5G modem. It is not fast as the X65 but it gives you good speeds.

Smartphones:

Phones with Dimensity 1300 AnTuTu v9
1. OnePlus Nord 2T 667021

MediaTek Dimensity 1300 is launched in this 1 smartphone. As you can see this smartphone score is different. OnePlus Nord 2T scores 667021, which is a lot better at this point.


Gaming Experience:

PUBG Mobile 68 FPS
[Ultra]
Call of Duty: Mobile 60 FPS
[High]
Fortnite 28 FPS
[Low]
Shadowgun Legends 71 FPS
[Ultra]
World of Tanks Blitz 88 FPS
[Ultra]
Genshin Impact 51 FPS
[Ultra]
Mobile Legends: Bang 60 FPS
[Ultra]
Device OnePlus Nord 2T
1080 x 2400

The gaming experience on this chipset is going to be a little faster than the MediaTek Dimensity 1200. This chipset is combined with the 1 core of Cortex-A78 which is an ultra-high performance core that is clocked on 3.00 GHz, and 3 cores of high performance which are clocked on 2.6GHz. The other 4 cores are based on Cortex-A55 and are clocked on 2GHz cores, there are also going to be little issues of heating. The frequency of this chipset is 3.0GHz, which is good for long-term gaming. This chipset also supports the LPDDR4x ram. This means there will be no issues with using this chipset in a long-term gaming session. This chipset also supports a 120Hz refresh rate. This will help in smooth performance with low latency. This chipset is can support PUBG MOBILE at 60FPS, this is because of the scores of the GPU.

So, this was my full review of the MediaTek Dimensity 1300 if you want to check out more articles like this then check the reviews in the menu. Also, do check out my YouTube channel. Thanks.
