Apple A14 Bionic Vs MediaTek Dimensity 1200which one is faster?

 Apple A14 Bionic Vs MediaTek Dimensity 1200:

Dimensity 1200 Vs A14 Bionic

Apple A14 Bionic Vs MediaTek Dimensity 1200- Hey what’s up guys? Welcome back to my website. In today’s article, I’m going to compare the MediaTek Dimensity 1200VS the Apple A14 Bionic chipset. I will be giving you some crazy comparisons between those chipsets. So, without any further delay, let’s start with specs.


Amazon Links:

Top smartphones

Cell Phone Chargers

Air buds

Smartphones Accessories

Apple Iphones

Samsung Phones

Tablets

Ipods

*Please Note: These are affiliate links. I may make a commission if you buy the components through these links. I would appreciate your support in this way!



MediaTek Dimensity 1200 Specs

Cores Octa (8)
Arm Cortex-A78 up to 3 GHz
Arm Cortex-A55 up to 2 GHz
Max Camera ISP 32MP + 16MP, 200MP
Max Video Capture Resolution 3840 x 2160
Memory Type LPDDR4x
Max Memory Frequency 4266Mbps
Max Memory Size 16GB
Storage Type UFS 3.1
GPU Type Arm Mali-G77 MC9
Max Display Resolution 2520 x 1080


Specs Of Apple A14 Bionic

Transistor count 11.8 billion
Core 6 Threads 6
2 x 3.1 GHz Firestorm
4 x 1.8 GHz Icestorm
Frequency 3100 MHz
L3 cache 8MB
Instruction set armv8.5-A
RAM type LPDDR5
Max bandwidth 42.7 Gbit/s
Max size 6 GB
Storage Type nvme TDP 6
GPU Apple GPU
Execution units 4
Supported Display 2732 x 2048
Video capture 4K at 60FPS

So, in today’s article, I’m comparing The MediaTek Dimensity 1200and the Apple A14 Bionic chipsets; I will be giving a complete review on differences,  pros and cons, benchmarks, Antutu 9, geekbench 5, gaming, and also some other crazy stuff about these processors. So, as we compare the 8 cores MediaTek Dimensity 1200with the six cores of the Apple A14 Bionic chipset; hence you will find the pros and cons of each chip, technical specs, and comprehensive tests and benchmarks like antutu and geekbench. So, let’s start with the review.


PROS OF MEDIATEAK DIMENSITY 1200

  • Media MediaTek Dimensity 1200 that it’s only using two more cores than A14 Bionic which is six core processor.

PROS OF APPLE A14 BIONIC

  • A14 Bionic chipset has a smaller size transistor five nanometer versus six nanometer the five centimeters fabricated processor used on A14 Bionic and a six-nanometer processor is used on MediaTek Dimensity 1200.
  • Shows better Antutu benchmark gains up to seven percent.
  • Apple A14 Bionic has the better setup instruction architecture.



Dimensity 1200 Vs A14 Bionic

The Antutu 9 benchmark, we will be comparing CPU, GPU, RAM in IO performance in different scenarios.


Apple A14 Bionic Vs MediaTek Dimensity 1200:

ANTUTU 9 BenchMarks

Dimensity 1200                                                  A14 Bionic
CPU 185735 185695
GPU 236097 285023
Memory 118192 118389
UX 132097 131689
Total score 667558 716022

The Antutu benchmark. Apple A14 Bionic crashes the Dimensity 1200. The CPU performance also goes to A14 Bionic that gaining 185620. The GPU performance also goes to A14 Bionic chipset scores 285864 instead of 233643 that on MediaTek Dimensity 1200. The memory MediaTek Dimensity 1200 gains more performance than the A14 Bionic because A14 Bionic uses the nvme. The MediaTek Dimensity 1200uses ufs 3.1 boost. The ux also gains more performance because the MediaTek Dimensity 1200can support 144 refresh rate and the A14 Bionic supports only 60Hz.

GEEKBENCH 5

  Dimensity 1200                      A14 Bionic +64%
Single-Core 979    1603
Multi-Core 3340                                      4129

Geekbench 5 scores. Apple A14 Bionic single core performance gains up to 64% beating the Dimensity to 1200 by almost 64 percent wow. The multi-core performance also beats the MediaTek Dimensity 1200by gaining 23 % that means the A14 Bionic has a better CPU speed and also has better image compression, fast detection, speech recognition, machine learning, camera shooting, html5, SQL lite is the AI works because A14 Bionic uses the better instruction set architecture than the MediaTek Dimensity 1200.

Dimensity 1200 Vs A14 Bionic



3DMARK WILD LIFE PERFORMANCE

Dimensity 1200                    A14 Bionic +80%
Stability 93% 77%
Graphics test 25 FPS 45 FPS
Score 4179 7555

Now let’s talk about 3d mark. The 3d mark shows the performance of A14 Bionic of 7523 beating the MediaTek Dimensity 1200by 80% percent wow I’m amazed to see that the Dimensity 1200 cannot outperform the A14 Bionic chipset because MediaTek Dimensity 1200is also a flagship processor but I’m also a little disappointed to see that the MediaTek Dimensity 1200scores only 4180. But the A14 Bionic chipset scores the 7523 beating the MediaTek Dimensity 1200by 80%. The gaming performance the PUBG Mobile support 90 fps on the MediaTek Dimensity 1200but the A14 Bionic is only kept on 60 fps. Because the Apple iPhone 12 pro max does not support the 90-hertz refresher or 120-hertz refresh rate.

CPU PERFORMANCE

MediaTek Dimensity 1200                                               Apple A14 Bionic
Cores



8 6
Architecture



1x 3 ghz – Cortex-A78

3x 2.6 ghz – Cortex-A78

 4x 2 ghz – Cortex-A55

2x 3.1 ghz – Firestorm

4x 1.8 ghz – Icestorm

Frequency

  MediaTek Dimensity 1200                                               Apple A14 Bionic
Frequency 3000 mhz                                                                      3100 mhz
Instruction set Armv8.2-A                                                                    Armv8.5-A
Process fabricated 6 nanometers                                                                     5 nanometers
TDP 10 W                                                          6 W

Now let’s talk about the CPU specs on both chipset. The MediaTek Dimensity 1200 is using 1 core at cortex a78 and three cores at A78 and 4 cores at cortex a55 are the power efficiency cores. But the apple A14 Bionic uses only two cores and the firestorm that is 3.1 gigahertz and four efficiency cores of 1.8 gigahertz in icestorm. The MediaTek Dimensity 1200uses 8 cores but A14 Bionic use 6 cores. The frequency is clearly ahead of the Apple A14 Bionic because it’s 3.1 GHz and the frequency of MediaTek Dimensity 1200is 3gigahertz. The A14 Bionic has a better instruction set and it’s also the latest one that’s why it’s gained more image compression and other AI stuff. The A14 Bionic is fabricated using 5NM.the MediaTek Dimensity 1200uses the 6nm processor and also the power efficient than 14 Bionic because it’s only 6 watt but the tdp of MediaTek Dimensity 1200is 10 watt so, that’s clearly ahead to the A14 Bionic chipset.


GPU PERFORMANCE

  MediaTek Dimensity 1200                                                                  Apple A14 Bionic
GPU name Mali-G77 MC9 Apple GPU
Architecture Valhall  n/a
GPU frequency 850 mhz                                                            n/a
Execution units 9 4
Shading units 144  n/a

Now let’s talk about the GPU scores on the MediaTek Dimensity 1200and the A14 Bionic. We don’t have much knowledge about the apple custom GPU but we do have knowledge of MediaTek Dimensity 1200. They are using the valhalla architecture. The GPU frequency is kept on at 850 megahertz and also execution units are 9. But apple GPU is unknown but we only can see the execution units is 4 and also the MediaTek Dimensity 1200has 144 shading units.


RAM SIZE

  MediaTek Dimensity 1200   Apple A15 Bionic
Memory type LPDDR4X LPDDR4X
Memory frequency 4266 mhz 4700Mhz
Bus 4x 16 Bit 4x 16 Bit
Max bandwidth 46 Gbit/s 42.7 Gbit/s
Max Ram size 16 GB 6 GB

Now let’s talk about the ram. They both use the same ram LPDDR4X. The dimensity memory frequency is 4266 MHz and the A14 Bionic is using the same ram but with a slightly high frequency of 4700 MHz.

The max memory bandwidth of the Apple A14 Bionic is 42.6GB per second.

And the Dimensity 1200 has 46Gbs which is slightly improved. The max size on this processor MediaTek Dimensity 1200is 16GB, which means this processor can support 16GB of ram but the Apple A14 can support only 6GB of ram so that’s a plus point for the Dimensity 1200.

Now let’s talk about the media. They both use the neural engine. MediaTek Dimensity 1200uses the ufs 3.1 and apple A14 Bionic uses the nvme. The max display resolution of the Apple A14 Bionic and the MediaTek Dimensity 1200is the same because that is QUAD HD PLUS resolution but the maximum camera resolution of the MediaTek Dimensity 1200is that they can support 200 megapixels of camera, but the Apple A14 Bionic chipset only can support 12 megapixel and their video capture and video playback is also the same video at 4k at 60fps. The audio codex and video codex are also the same.



Now let’s talk about connectivity. They both support the 5G on these phones, but the MediaTek Dimensity 1200can go LTE Cat19 but A14 Bionic is only kept on lte cat18; also they both support the 5H, download speed and upload speeds are also the same on both phones. The MediaTek Dimensity 1200uses the 5.2 Bluetooth version but the A14 Bionic uses the 5.0. The MediaTek Dimensity 1200is also a newer processor because it was announced in January 2021, but the A14 Bionic was announced in September 2020. These both are the flagship performance processors.

So, that was all for this Article. If you want to buy an apple so make sure you go with the newer version of the Apple A15 Bionic chipset. But if you are an android user so I will always recommend MediaTek Dimensity 1200because it’s a capable chipset with amazing features and also have a better instruction set and can support a 200-megapixel camera also can support 144-hertz refresh rate and also have the 5.2 Bluetooth newer version. So, if you are an Apple user I would recommend a newer processor, and if you are a MediaTek user and going for mid-range devices because a lot of manufacturing companies are going with Dimensity 1200 because of their mid-range devices. So, I also recommend buying that instead if you want to buy a flagship performance processor. So, I also recommend a newer version of the Dimensity processor.
