How to use GSM and Bluetooth Together To monitor Any Sensors wirelessly using Arduino

(Last Updated On: June 27, 2020)

Bluetooth

GSM and Bluetooth Together, Project Description:

GSM and Bluetooth Together- In this Tutorial, you will learn how to use GSM and Bluetooth together to monitor any Sensors. In this project, the sensors can be monitored wirelessly using the GSM sim900A module and HC-05 Bluetooth module.  In this tutorial, we will cover

  1. Bluetooth settings using AT commands, like setting the pin code, changing the name of the Bluetooth module
  2. dht11 sensor datasheet, pinouts, and soldering
  3. GSM module pinouts and explanation
  4. Complete circuit diagram explanation
  5. Programming
  6. testing

For the complete step by step explanation Watch Video Tutorial given at the end of this Article.


The components and tools used in this project can be purchased from Amazon, the components Purchase links are given below:

Arduino Uno:
Mega 2560:
dht11 sensor:
HC-05 Bluetooth Module:
GSM sim900A:
5V regulated power supply/Adaptor for GSM sim900A:

*Please Note: These are affiliate links. I may make a commission if you buy the components through these links. I would appreciate your support in this way!

Why we use GSM and Bluetooth together?

While we are at the site near to the hardware then there is no need to use the GSM for monitoring the Sensor. The best way can be to use the Bluetooth module. We can design our own android cell phone application to monitor different sensors.

GSM and Bluetooth Together Arduino Circuit Diagram:

Bluetooth

Download:

Android cell phone application:gms and bluetooth together

GSM and Bluetooth Arduino Programming:

Both the modules, GSM SIM900A and HC-05 Bluetooth communicates with the Arduino using the Serial communication. As you know, in Arduino we have only one Serial Port, which can be used only for one device at a time unless you use some kind of a multiplexer. But instead of using complex hardware components, we can define other Serial ports using the SoftwareSerial library.

This way we can connect one device with the Arduino’s default Serial port, and the other device with our own defined Serial port. This is the reason I defined a serial port with the name nodemcu on pins 2 and 3.

Watch Video Tutorial:
